Generation 5
PA5W
Inovance Automotive Gen 5 range-extender 5-in-1 eAxle, consisting of a P1 generator, generator controller, P3 asynchronous drive motor, drive inverter, and P3 transmission system. The eAxle adopts an oil-cooled architecture, achieving extreme compact size and lightweight design. The P1 performance is matched with a 1.5T engine, capable of covering the auxiliary drive requirements for B/C/D-class four-wheel-drive REEV in new energy vehicles.
Product Features
High Compatibility
Compatible with high/low voltage, synchronous/asynchronous motors: ASM P3 160 kW/2500 N·m.
Low Energy Consumption
P3 system drag loss < 650 W @ wheel-end 1000 RPM, contributing to improved vehicle energy efficiency.
Lightweight Design
Assembly weight < 107 kg, a 10% reduction compared to the previous generation.
Superior NVH
Quiet and comfortable operation, with targeted eMotor and gear-shaft design achieving noise levels < 65 dB.
High Reliability
Unique shaft electrical scheme design ensures no corrosion throughout the lifecycle under high voltage.
Product Parameters
-
Dimensions577 mm x 390 mm x 565 mm
-
Rated operating voltage540 V
-
Operating voltage range335 V to 640 V
-
TM peak power160 kW at 540 V
-
TM transmission Ratio11.217
-
Speed at drive wheel end> 1400 RPM
-
Torque at drive wheel end2500 N·m
-
GM continuous generation power65 kW at 540 V
-
Weight107 kg
-
WLTC generation efficiency≥ 92%
