Generation 3
LM39
Flat-wire motor specifically developed for N2-class vehicle models.
Product Features
Stable Supply
Our R&D and production resources ensures stable supply.
High Efficiency
Flat-wire technology improves system efficiency by 1.5% and increases peak torque density by 25%.
High Quality
Resolves the industry-wide condensation issue.
Superior NVH
Flat-wire technology enables quiet and comfortable operation with improved motor NVH.
Ease of Use
Enables seamless replacement across product generations.
Broad Compatibility
Compatible with high/low voltage platforms and various power/torque ratings, adaptable to different vehicle models.
Product Parameters
-
Dimensions286 mm x 337 mm x 347 mm
-
CHTC efficiency≥ 95%
-
Weight49 kg±2 kg
-
Peak torque300 N·m to 500 N·m
-
Maximum speed12,000 RPM
-
Continuous output power50 kW to 100 kW
-
Peak output torque300 N·m to 500 N·m
-
Peak output power105 kW to 200 kW
-
Operating voltage range290 V to 450 V/350 V to 750 V
-
Rated operating voltage336 V/540 V
