Generation 4
LC43
Inovance Automotive Gen 4 domain-controlled X-in-1 combined charging system. It integrates and is compatible with control functions such as VCU, BMS, MCU, and TMS, featuring a more compact size and higher reliability. It facilitates the evolution of the vehicle's electronic and electrical architecture towards centralized domain control and is suitable for the full series of N1-class vehicle models.
Product Features
High Scalability
OBC supports multiple power configurations, EVCC function, cyber security, and V2L/V2G discharge.
High Reliability
10-year/600,000 km lifespan design, meeting full vehicle lifecycle requirements.
Platform Design
Comprehensive power distribution functions supporting REEV, PHEV, 2WD, and 4WD vehicle applications, as well as specialized models such as those with power take-off (PTO).
High Compatibility
Ultra-integrated X-in-1 combined charging system designed for domain control architecture, integrating control functions including VCU, BMS, MCU, and TMS. Customizable development supported.
Product Parameters
-
Domain control functionVCU/BMS/TMS/MCU strategy
-
PDU distributionMCU/PTC/EAC/power take-off (PTO)/range-extender/pre-charge
-
EMC classClass 3
-
DC/AC inverter efficiency> 94%
-
DC/AC inverter power6 kVA
-
DC/DC weighted efficiency> 93.5%
-
DC/DC rated output current210 A
-
DC/DC power3 kW
-
OBC full-load average efficiency≥ 94%, 95% optional
-
OBC power6.6 kW
11 kW -
Rated voltage400 V
