Generation 4
LA4G
Inovance Automotive Gen 4 2-in-1 eAxle, suitable for the full series of N1-class vehicles ranging from 1.8T to 3.5T.
Product Features
High Efficiency
The 2-in-1 eAxle achieves over 94.5% CLTC efficiency.
Platform Design
Series of power and torque ratings with motor speed up to 16,000 RPM, meeting diverse vehicle power requirements.
High Adaptability
Random vibration rating of 10.95·g; supports both front and rear drive applications; supports integration with the reducer to form half-shaft 3-in-1 or X-in-1 systems, or with the rear axle to form an integrated electric beam (e-beam).
High Reliability
Comprehensive optimization addresses industry challenges including spline wear and condensation, meeting 100,000 km/600,000 km maintenance-free operation requirements.
High Power Density
Leading integrated inverter and eMotor design, a major 4th-generation upgrade, reduces the volume and weight by 20%.
Product Parameters
-
DimensionsX ≤ 311 mm; Y ≤ 300/270 mm; Z ≤ 250 mm
-
Weight30 kg
26.5 kg -
Vibration class10.95·g
-
Peak speed16,000 RPM
-
Peak torque260 N·m
180 N·m -
Peak power110 kW at 60s/75 kW at 30s
-
Operating voltage range250 VDC to 480 VDC
-
System compositioneMotor +inverter
